Fault Injection Into AWS

This guide will walk you through injecting network faults into AWS ECS platform. Without changing any application code.

Prerequisites
How about other AWS services?

fault supports ECS natively as well as EKS through the fault inject kubernetes command. What about EC2 or Lambda?

Both may be featured in the future indeed if they are asked for by the community.

Inject Latency Into a ECS Service

ECS is the AWS platform to run workload using containers. The approach taken by fault is to add a sidecar container to an existing ECS task definition. This container then becomes the entrypoint of network traffic, meaning we switch the the Load Balancer target group to point to the new container's port. fault is configured to then route all traffic from that port to the application's port transparently. When done, we rollback to the previous task definition and load balancer configuration.

raffic Before fault Is Injected

---
config:
  theme: 'default'
  themeVariables:
      'git0': '#ff00ff'
  gitGraph:
    showBranches: true
    showCommitLabel: true
    mainBranchName: 'normal'
---
gitGraph
       commit id: "LB"
       commit id: "Target Groups"
       commit id: "Target"
       commit id: "ECS Service"
       commit id: "Application Container"

Traffic After fault Is Injected

---
config:
  theme: 'default'
  themeVariables:
      'git0': '#ff00ff'
      'git1': '#00ffff'
  gitGraph:
    showBranches: true
    showCommitLabel: true
    mainBranchName: 'normal'
---
gitGraph
       commit id: "LB"
       commit id: "Injected" type: HIGHLIGHT
       branch fault
       commit id: "Target Groups"
       commit id: "ECS Service"
       commit id: "fault Container"
       commit id: "Application Container"
       checkout normal
       merge fault id: "Rolled back" type: HIGHLIGHT

  • Create a basic ECS service

    You may want to follow the official AWS documentation to create a service.

    Make sure to associate the service to a target group attached to a load balancer.

  • Inject fault into the ECS service

    The following injects a 800ms into the service response time.

    fault inject aws \
    --region <region>  \  # (1)!
    --cluster <cluster-name> \  # (2)!
    --service <service-name> \  # (3)!
    --duration 30s \  # (4)!
    --with-latency --latency-mean 800
    1. The AWS region where your ECS service is running
    2. The AWS ECS cluster name
    3. The AWS ECS service name
    4. Optional duration after which the injection rollbacks. If unset, the user input is expected

    When you do not explicitly set the service, fault lets you pick up one from the CLI:

    fault inject aws \
    --region <region>  \
    --cluster <cluster-name> \
    --with-latency --latency-mean 800
? Service:
> hello
[↑↓ to move, enter to select, type to filter]

    Once started, a new revision of the service will be deployed with the fault process running as a sidecar container of the service's main container. It will expose a port to receive traffic and route it to the application.
